DS-2PT3306IZ-DE3
Model: DS-2PT3306IZ-DE3 – Hikvision Network PanoVu Cameras
Details: PanoVu Mini Series IR Network PTZ Camera
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
DS-2PT3306IZ-DE3 Overview
Quick Specs Figure 1 shows the appearance of DS-2PT3306IZ-DE3.
Table 1 shows the Quick Specs.
| Image Sensor | Three 1/2.8″ progressive scan CMOS |
| Min. Illumination | Color: 0.05 Lux @(F2.0, AGC ON)B/W: 0.01 Lux @(F2.0, AGC ON)0 Lux with IR |
| Lens | 2 mm |
| Angle of View | Horizontal field of view: 128.5° × 3Vertical field of view: 75.7° |
| Main Stream | Main stream:(Sub-stream not enabled)50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)Main stream:(Sub-stream enabled)50 Hz: 20 fps (1920 × 1080, 1280 × 960, 1280 × 720)60 Hz: 20 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream | 50 Hz: 20 fps (704 × 576, 640 × 480, 352 × 288)60 Hz: 20 fps (704 × 480, 640 × 480, 352 × 240) |
| Image Compression | Main stream: H.265/H.264Sub-stream: H.265/H.264/MJPEG (MJPEG is only supported by channel 1)H.264 with Main Profile/High Profile, H.265 with Main Profile |
| Basic Event Detection | Motion Detection, Video Tampering Detection, Exception |
| Smart Image Enhancement | Digital WDR/HLC/BLC/3D DNR/Defog/Regional Exposure |
| IR | 10 m |
| Smart Detection | Audio Exception Detection, Intrusion Detection, Line Crossing Detection |
| Audio Input | 1-ch audio input |
| Audio Output | 1-ch audio output |
| Audio compression | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2 |
| Protocol | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour |
| Application programming | Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform |
| User/Host Level | Up to 32 users,3 Levels: Administrator, Operator and User |
| Security Measures | User authentication (ID and PW); Host authentication (MAC address); IP address filtering |
| Web Browser | IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
| Ethernet | 1 RJ45 10 M/100 M Ethernet |
| Power supply | 12 VDC & PoE+ (802.3 at, class 4)Max.20 W (Max. 6 W for IR) |
| Working temperature | -10°C to 50°C (14°F to 122°F) |
| Working humidity | ≤ 90% |
| Material | PC & Aluminum alloy |
| Protection Level | IP66, TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimensions (W×D×H) | Φ 183 mm × 76 mm (Φ 7.20″ × 2.99″) |
