DS-7716NI-E4
Model: DS-7716NI-E4 – Hikvision NVR 7700 Series
Details: 160/80 Mbps In/Out Bandwidth, 720/1080p@30fps/ 3MP/ 5MP/ 6MP Max Resolution, Video output: VGA & HDMI + Audio I/O: 1 In/ 1 Out + Alarm I/O: 16 In/4 Out, 4 x 6TB SATA
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
DS-7716NI-E4 Overview
Quick Specs Figure 1 shows the appearance of DS-7716NI-E4.
Table 1 shows the Quick Specs.
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input | 16-ch |
| Remote connection | 128 |
| Incoming bandwidth | 160Mbps |
| Outgoing bandwidth | 80Mbps |
| HDMI/VGA output | 1-ch, resolution:1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Recording Resolution | 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate | Main stream: 50 fps (P) / 60 fps (N)Sub-stream: 50 fps (P) / 60 fps (N) |
| Capability | 16-ch@4CIF, 12-ch@720P, 6-ch@1080P |
| Live view / Playback | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| SATA | 4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs |
| Capacity | Up to 6TB capacity for each HDD |
| Network Interface | 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| USB Interface | Front panel: 2 × USB 2.0Rear panel: 1 × USB 3.0 |
| Alarm In | 16-ch |
| Alarm Out | 4-ch |
| Power Supply | 100~240VAC |
| Consumption (without hard disk and POE) | ≤ 20W |
| Working Temperature | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity | 10 % ~ 90 % |
| Chassis | 19-inch rack-mounted 1.5U chassis |
| Dimensions | 445 × 390 × 70mm (17.5 ×15.3 × 2.8 inch) |
