IPC6212-IR(12mm)
Model: Huawei IPC6212-IR(12mm) 1.3MP Network IR Bullet Camera
Details: Huawei IPC6212-IR(12mm) 1.3MP Network IR Bullet Camera(30fps,f=12mm,FE,IR 30m)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
IPC6212-IR(12mm) Overview
Quick Specs Figure 1 shows the appearance of IPC6212-IR(12mm).
_1.png)
Table 1 shows the Quick Specs.
| Image sensor | 1/3’’ 1.3MP Progressive Scan CMOS |
| Max. Image Resolution | 1280(H)× 960(V) |
| Min. IlluminationDay &Night Mode | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IRAuto(ICR)/ Color / B/W /Timing/ Alarm Trigger |
| IR Distance | 20~30m |
| Electronic shutter speedGain control | 1/3 ~ 1/100,000sSupported |
| White balance | MWB/AWB1/Locked WB/Fluorescent Lamp/incandescent Lamp/Warm Light Lamp/Natural Light |
| Wide Dynamic RangeBacklight compensation | SupportedSupported |
| Lens MountLens | ø146mm,12mm fixed lens optional; Max Aperture: F2.0 |
| Horizontal angle of view | IPC6212-IR(6mm): 46°; IPC6212-IR(12mm): 22° |
| Image Compression | H.264 MP/BP, MJPEG |
| Video resolution and frame rateVideo Bitrate | 50Hz: 25fps (1280 × 960), 25fps (1280 × 720)60Hz: 30fps (1280 × 960), 30fps (1280 × 720)32Kbps ~ 12Mbps |
| Multiple streams | Main Stream/Sub Stream |
| ROI EncodingCorridor Format | SupportedSupport aspect ratio 9:16 |
| Audio Encoding Format | G.711/G.726/MP2L2 |
| Audio CommunicationCommunication Interface | Voice intercom(Pick-up is needed), voice broadcasting, channel associated voice1 RJ45 10M/100M Adaptable Ethernet Interface,1 RS-485 Interface(PELCO-P/D) |
| Alarm Interface | 1 alarm input /1alarm output |
| Audio interfaceStorage Interface | 1-channel audio input/1-channel audio OutputSupport Micro SD/SDHC /SDXC Card (Max. 64G) |
| Analog Output | 1 CVBS Composite Analog Video Output |
| Motion DetectionPrivacy Masking | SupportedSupported |
| PU Access Protocolnetwork protocol | ONVIF 2.2ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Digital Watermark | Supported |
| Max. Video Streams AccessingingSecurity Measures | Supported max. 6 channels video streams accessingUser name and password authentication; Support 802.1x |
| Web Browser | IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +, support multi-language; Windows XP, Windows7, Windows8 |
| Other functions | 2D/3D Noise reduction, Front-end Recording, Front-end Capture, IP Address Filtering, MTU Configuration, Electronic mage Stabilization |
| Power supply | DC12V±10% / PoE(802.3af) |
| Power consumptionOperating temperature / humidity | Max. 5.5W (7.5 W for ICR Switch)Operating temperature: -30ºC ~ 60ºCOperating humidity: 5% ~ 90% (Non-condensing) |
| Protection LevelDevice NetWeightPhysical Product Appearance | IP661000g95×105×258.6mm |
