PFM920I-6U-U

Name: PFM920I-6U-U
SKU: PFM920I-6U-U
Availability: OutOfStock

$0.00

Model: PFM920I-6U-U – Dahua Cameras Accessories
Details: Dahua UTP CAT6 Cable
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

Out of stock

Add to compare

Add to wishlist

Add to quote

SKU: PFM920I-6U-U Categories: Dahua Cameras Accessories, Dahua Other Products, Dahua Video Surveillance, Video Surveillance

Security/Data Center/Networking

End-to-End Project Support
Smart Industrial Solutions
Global Expert Team
Certified ICT Professionals

Ask the Experts

24/7 Online Service

We're Always Here

+1-737-282-1616 (USA)

+971 58 6900 135 (United Arab Emirates)

+966 55 0033 948 (Saudi Arabia)

Partner with Us

Join Global Partner Program in Pakistan

Get Started

MAECENAS IACULIS

Vestibulum curae torquent diam diam commodo parturient penatibus nunc dui adipiscing convallis bulum parturient suspendisse parturient a.Parturient in parturient scelerisque nibh lectus quam a natoque adipiscing a vestibulum hendrerit et pharetra fames nunc natoque dui.

ADIPISCING CONVALLIS BULUM

Vestibulum penatibus nunc dui adipiscing convallis bulum parturient suspendisse.
Abitur parturient praesent lectus quam a natoque adipiscing a vestibulum hendre.
Diam parturient dictumst parturient scelerisque nibh lectus.

Scelerisque adipiscing bibendum sem vestibulum et in a a a purus lectus faucibus lobortis tincidunt purus lectus nisl class eros.Condimentum a et ullamcorper dictumst mus et tristique elementum nam inceptos hac parturient scelerisque vestibulum amet elit ut volutpat.

HPE 840G7-Z97 i7-10510U/16G/512G SSD/Integrated Graphics Card/FHD 1920*1080 Original price was: $1,146.65.Current price is: $1,089.32.
HPE 840G7-Q17 i7-10510U/8G/512G SSD/Integrated Graphics Card/FHD 1920*1080 Original price was: $1,010.65.Current price is: $960.12.
HPE 840G7-P99 i5-10210U/16G/512G/Integrated Graphics Card/FHD 1920*1080 Original price was: $1,010.65.Current price is: $960.12.
HPE 840G7-Q16 i5-10210U/8G/256G/Integrated Graphics Card/FHD 1920*1080 Original price was: $924.80.Current price is: $878.56.

Description

Description

PFM920I-6U-U Overview

Quick Specs Figure 1 shows the appearance of PFM920I-6U-U.

Table 1 shows the Quick Specs.

Material	PVC
Diameter	6.5 mm ± 0.3 mm
American Wire Gauge	23AWG
Min. Average Thickness	0.5 mm
Color (4 Pairs)	Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown
Specification	500D
Color	White
Max. DC Resistance of a Single Conductor	8.45Ω/100 m
Min. Insulation Resistance	5000MΩ·km
Max. DC Resistance Unbalance	2% (pair intra), 4% (pairs inter)
Dielectric Strength	No breakdown with 1KV DC for 1 min
Characteristic Impedance	100 ± 15Ω
Near End Cross Talk	≥39.30 dB/100 m@250 MHz
Max. Attenuation	33 dB/100 m@250 MHz
Return Loss	≥17.3 dB/100 m@250 MHz
Tensile Strength	Sheath≥13.5 MPa, insulation≥13.8 MPa
Elongation at Break	Sheath≥200%, insulation≥300%
Installation Bending Radius	>8 times of outer cable diameter
Conductor Elongation at Break	≥20%
Shrinkage of Insulation	≤5%
Color Migration Resistance of Insulation	No migration
Sheath Tensile Strength and Elongation at Break after Aging	≥12.5 MPa, ≥100%
Low Temperature Bending Test	No cracking after the test
Heat Shock Test	No cracking after the test
Operation Temperature	–20°C to +60°C (–4°F to 140°F)
Installation Temperature	0°C to +50°C (32°F to 122°F)
Storage Temperature and Humidity	–10°C to +40°C (14°F to 104°F), <60% (RH)
Vertical Fire Propagation Test	Comply with UL1685
Length	305.0 m (1000.66 ft) ± 1.5 m (4.92 ft)
Packaging Dimensions	390.0 mm x 390.0 mm x 247.0 mm (15.37″x15.37″x9.73″) (L × W × H)
Packaging Method	305.0 m (1000.66 ft) a carton, one protection carton with 2 cartons inside
Net Weight	≥12.9 kg (28.44 lb)
Gross Weight	≥13.9 kg (30.64l b)
Executive Standard	ANSI/TIA 568-C.2, UL1685
Certification	UL CM
