Sold out
Juniper QFX5100-48SH-AFO
Model: Juniper QFX5100-48SH-AFO Switches
Details: QFX5100-48SH-AFO Hardware Only Appliance
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
Juniper QFX5100-48SH-AFO Overview
Quick Specs Figure 1 shows the appearance of Juniper QFX5100-48SH-AFO.
Table 1 shows the Quick Specs.
| Product Type | Switch – 48 ports – L3 – Managed – Stackable |
| Form Factor | Rack-mountable 1U |
| Ports | 48 x 10 Gigabit Ethernet SFP+ / 40 Gigabit Ethernet QSFP+ |
| Performance | Throughput: 1.44 Tbps | Switching capacity: 2.88 Tbps | Latency (SFP+): 550ns |
| MAC Address Table Size | 288K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | BGP, RIP-1, RIP-2, IGMP, VRRP, OSPF-2, PIM-SM, PIM-DM, OSPFv3, PIM-SSM, MSDP, static IPv4 routing, static IPv6 routing, ECMP |
| Features | Layer 3 switching, layer 2 switching, DHCP support, VPN support, ARP support, MPLS support, VLAN support, auto-uplink (auto MDI/MDI-X), temperature sensor, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Jumbo Frames support, Uni-Directional Link Detection (UDLD), Management Information Base (MIB), Class of Service (CoS), DiffServ Code Point (DSCP) support |
| RAM | 2 GB |
| Flash Memory | 1 GB |
| Power Supply Included | Yes |
| Power Redundancy | Optional |
| Power Consumption Operational | Max: 300W |
| Interfaces | 48 x 10G SFP+ / 40G QSFP+ ports | 1 x Management port – RJ-45 | 1 x Console port – RJ-45 | 1 x USB port Type A |
| Software Included | Junos OS |
| Dimensions (WxDxH) | 17.4 in x 18.4 in x 1.7 in |
| Environmental Parameters | Min Operating Temperature: 32 ��F | Max Operating Temperature: 104 ��F | Humidity Range Operating: 10 – 85% (non-condensing) |
| Compliance Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ab (LLDP) |
| Encryption Algorithm | SSL |
| Management Protocol | SNMP, RMON, SSH, CLI |
| Warranty | 1-year warranty |
Get more information
Do you have any question about the Juniper QFX5100-48SH-AFO?
Contact us now via Live Chat or sales@metafinitivetech.com
