Name: A901-6CZ-FT-D
SKU: A901-6CZ-FT-D
Availability: OutOfStock

A901-6CZ-FT-D

$0.00

Model: A901-6CZ-FT-D Cisco ASR 901 Series Chassis
Details: Cisco A901-6CZ-FT-D Cisco ASR 901 10G Router – TDM+Ethernet Model – DC Power
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

Out of stock

A901-6CZ-FT-D Overview

Quick Specs Figure 1 shows the appearance of A901-6CZ-FT-D.

Table 1 shows the Quick Specs.

Description	Cisco ASR 901 Series Aggregation Services Router Chassis, Ethernet and TDM interfaces, 10 GE, DC power, USB
Dimensions (H x W x D)	1.7 x 17.5 x 9.1 in. (43.2 x 444.5 x 231 mm), 1RU
Weight	8.15 lb (3.7 kg)
Memory	Flash memory: 128 MB (onboard flash)System memory: 1 GB (DDR3)
Rack mounts	10 GE models:· 19-in. rack mount option· 23-in. rack mount option· ETSI rack mount option· Recessed rack mount option for 19-in. cabinets· Recessed rack mount option for 23-in. cabinets· Recessed rack mount option for ETSI cabinets· Wall mount option
Ethernet ports	4 100/1000 RJ-45 Gigabit Ethernet ports4 x 1 SFP Gigabit Ethernet ports4 x 1 Gigabit Ethernet Combo ports2 x 10 Gigabit Ethernet ports (10 GE models only)
TDM ports	8 T1/E1
Console port	1 (up to 115.2 Kbps)
USB port	1 supported on the following chassis models:
External timing ports	BITS input, 10-MHz input/output, 1 PPS input/output, ToD interface, and SyncE
Fans	10 GE models: three fans, with redundancy
Air flow	10 GE models: 57 cfm
Cabling	Front-panel access cabling and LED indicators
Power supplies	2 power supplies (DC only); module redundancy: 1:1
Mean Time Between Failure (MTBF)	378,490 hours
Power consumption	10 GE models: dual DCMaximum DC-input power and power dissipation at 48V supply:· A901-6CZ-F-D: 58W· A901-6CZ-FS-D: 59W· A901-6CZ-FT-D: 67W
Power rating	10 GE models:· DC-input voltage rating: 24 VDC, -48 VDC, -60 VDCDC-input current rating: 4A maximum
Power connector	6-position 2-tier stacked connector comprising two feeds, A and B DC power (AMPHENOL ELVA06100), and 3‑position mating connectors for each feed (AMPHENOL ELVP03100)
Operating temperature	-40 to 149°F (-40 to 65°C)
Nonoperating temperature	-40 to 158°F (-40 to 70°C)
Relative humidity	10% to 85%, noncondensing, ±5 %
Operational altitude	13,000 ft (4000m) maximum 104°F (40°C) ambient
Acoustic noise	10 GE models: 61 dBA with 19 cfm fan
