AntiDDoS8030-BASE-AC
Model: AntiDDoS8030-BASE-AC 0235G783 Huawei Anti-DDoS8000 DDoS Protection Systems
Details: AntiDDoS8030 S8030-BASE-AC Basic Configuration(include X3 AC Chassis,2*MPU)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
AntiDDoS8030-BASE-AC Overview
Quick Specs Figure 1 shows the appearance of AntiDDoS8030-BASE-AC.
Table 1 shows the Quick Specs.
| Throughput | Up to 120 Gbit/s |
| Throughput/Slot | Up to 80 Gbit/s |
| Mitigation Rate/Slot | Up to 60 Mpps |
| Latency | 80 μs |
| Expansion Slots | 3 |
| Expansion LPU | FW-LPUF-120, 2 sub-slots |
| Expansion Interfaces | 24 x GE (SFP); 5 x 10 GE (SFP+); 6 x 10 GE (SFP+); 12 x 10 GE (SFP+); 1 x 40 GE (CFP); 1 x 100 GE (CFP) |
| Height x Width x Depth | DC: 175 mm x 442 mm x 650 mm (4U)AC: 220 mm x 442 mm x 650 mm (5U) |
| Weight | DC chassis: 15 kg (empty), 30.7 kg (full)AC chassis: 25 kg (empty), 40.7 kg (full) |
| Power Supply | Rated input voltage:DC: -48VAC: 175V to 264V; 50 Hz/60 HzMaximum input voltage range:DC: -72V to -38VAC: 90V to 264V; 50 Hz/60 Hz |
| Power Consumption | 1 x FW-LPUF-120 + 2 x ADS-SPUC-B + 2 x ADS-SPC-80-01:DC: 1,066W (avg.), 1,272W (max.)AC: 1,185W (avg.), 1,414W (max.) |
| Power Redundancy | DC: Double hot-swappable power modulesAC: Double hot-swappable power modules |
| Operating Temperature | 0°C to 45°C (long-term), -5°C to 50°C (short-term) |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 5% RH to 85% RH, non-condensing (long-term), 5% RH to 95% RH, non-condensing (short-term) |
| Storage Humidity | 0% RH to 95% RH |
| Safety Certifications | Electro Magnetic Compatibility (EMC) certificationCB, Rohs, FCC, MET, C-tick, and VCCI certification |
| Defense against protocol abuse attacksDefense against Land, Fraggle, Smurf, WinNuke, Ping of Death, Teardrop, and TCP error flag attacks | Web application protectionDefense against HTTP GET flood, HTTP POST flood, HTTP slow header, HTTP slow post, HTTPS flood, SSL DoS/DDoS, WordPress reflection amplification, RUDY, and LOIC attacks; packet validity check |
| Defense against scanning and sniffing attacksDefense against address and port scanning attacks, and attacks using Tracert packets and IP options, such as IP source route, timestamp, and record route | DNS application protectionDefense against DNS query flood, DNS reply flood, and DNS cache poisoning attacks; source limit |
| Defense against network-type attacksDefense against SYN flood, SYN-ACK flood ACK flood, FIN flood, RST flood, TCP fragment flood, UDP flood, UDP fragment flood, IP flood, ICMP flood, TCP connection flood, sockstress, TCP retransmission, and TCP empty connection attacks | SIP application protectionDefense against SIP flood/SIP methods flood attacks, including Register, Deregistration, Authentication, and Call flood attacks; source limit |
| Defense against UDP-based reflection amplification attacksDefense against NTP, DNS, SSDP, Chargen, TFTP, SNMP, NetBIOS, QOTD, Quake Network Protocol, Portmapper, Microsoft SQL Resolution Service, RIPv1, and Steam Protocol reflection amplification attacks | FilterIP, TCP, UDP, ICMP, DNS, SIP, and HTTP packet filters |
| Attack signature databaseRUDY, slowhttptest, slowloris, LOIC, AnonCannon, RefRef, ApacheKill, and ApacheBench attack signature databases; automatic weekly update of these signature databases | IP reputationTracking of most active 5 million zombies and automatic daily update of the IP reputation database to rapidly block attacks; local access IP reputation learning to create dynamic IP reputation based on local service sessions, rapidly forward service access traffic, and enhance user experience |
| Management functionsAccount management and permission allocation; defense policy configuration and report display based on Zones (up to 100,000 Zones, namely tenants); device performance monitoring; source tracing and fingerprint extraction through packet capture; email, short message, and audio alarms; log dumping; dynamic baseline learning | Report functionsComparison of traffic before and after cleaning; top N traffic statistics; application-layer traffic comparison and distribution; protocol distribution; traffic statistics based on the source location; attack event details; top N attack events (by duration or number of packets); distribution of attacks by category; attack traffic trend; DNS resolution success ratio; application-layer top N traffic statistics (by source IP address, HTTP URI, HTTP HOST, and domain name); download of reports in HTML/PDF/Excel format; report push via email; periodical generation of daily, weekly, monthly, and yearly reports |
| Traffic diversionSupports manual, and PBR or BGP based automatic traffic diversion | Traffic injectionSupports static route injection, MPLS VPN injection, MPLS LSP injection, GRE tunnel injection, Layer 2 injection, PBR based injection, etc |
