AR0MSDE12A00
Model: Huawei Router Ethernet Interface Card AR0MSDE12A00
Details: 2-Port Fractional Channelized E1/T1 WAN Interface Card
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
AR0MSDE12A00 Overview
Quick Specs Figure 1 shows the appearance of AR0MSDE12A00.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Product Name | AR0MSDE12A00 |
| Interface Type | Fractional Channelized E1/T1 |
| Number of Ports | 2 |
| WAN Support | Yes |
| Connector Type | RJ-48C |
| Data Rate | Up to 2.048 Mbps per channel |
| Protocol Support | PPP, HDLC, Frame Relay |
| Network Standard | ITU-T G.703, G.704 |
| Port Density | 2 ports per module |
| Power Consumption | 10W (maximum) |
| MTBF | 250,000 hours |
| Operating Temperature | -40°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Certifications | CE, FCC, RoHS |
| Form Factor | Plug-in card |
| Dimensions (HxWxD) | 130 mm x 220 mm x 30 mm |
| Product Code | 02312SKL01 |
| Warranty | 1 year |
