-5%
ASMAM0002
Model: Huawei Next Generation AS1200 Series Router Omnidirectional antenna ASMAM0002
Details: Omnidirectional antenna
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
ASMAM0002 Overview
Quick Specs Figure 1 shows the appearance of ASMAM0002.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | ASMAM0002 |
| Antenna Type | Omnidirectional |
| Frequency Range | 698 MHz ?C 2700 MHz |
| Gain | 8 dBi |
| VSWR | <1.5:1 |
| Impedance | 50 ° |
| Polarization | Vertical |
| Maximum Power | 100 W |
| Connector | N-Female |
| Beamwidth Horizontal | 360° |
| Beamwidth Vertical | 8° |
| Antenna Length | 600 mm |
| Mounting Type | Pole Mount |
| Operating Temperature | -40°C to +70°C |
| Wind Load | 160 km/h |
| Radome Material | ABS |
| Ingress Protection | IP67 |
| Lightning Protection | DC Grounded |
| Color | White |
