ASMAM0003
Model: Huawei ASMAM0003 Isotropic Antenna
Details: Isotropic Antenna
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
ASMAM0003 Overview
Quick Specs Figure 1 shows the appearance of ASMAM0003.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | ASMAM0003 |
| Type | Isotropic Antenna |
| Frequency Range | 2.4 GHz – 2.5 GHz |
| Impedance | 50 Ohms |
| VSWR | < 1.5:1 |
| Gain | 2 dBi |
| Polarization | Linear, Vertical |
| Connector Type | SMA Male |
| Operating Temperature | -40°C to 85°C |
| Storage Temperature | -45°C to 90°C |
| Radome Material | ABS |
| Mounting Type | PCB Mount |
| Durability | 500 Cycle |
| Dimensions | 108 mm x 12 mm |
| IP Rating | IP67 |
| RoHS Compliance | Yes |
| Shock Resistance | 10G |
| Humidity | 95% RH |
| Antenna Pattern | Omnidirectional |
| Warranty | 2 Years |
