-5%
C-NIM-1X
Model: C-NIM-1X – Cisco Catalyst 8000 Series Edge Platforms Modules & Cards Series
Details: Cisco NIM module 1-port 10G SFP/SFP+ with MACSec
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
C-NIM-1X Overview
Quick Specs Figure 1 shows the appearance of C-NIM-1X.
Table 1 shows the Quick Specs.
| Brand | Cisco |
| Model | C-NIM-1X |
| Product Type | NIM Module |
| Port | 1-port |
| Supported Interface | 10G SFP/SFP+ |
| MACSec Support | Yes |
| Form Factor | Plug-in module |
| Data Transfer Rate | 10 Gbps |
| Compatibility | Cisco ISRs |
| Connector Type | SFP, SFP+ |
| Protocols | IEEE 802.1AE (MACSec) |
| Operating Temperature | 0 to 40??C (32 to 104??F) |
| Storage Temperature | -40 to 70??C (-40 to 158??F) |
| Operating Humidity | 5% to 95% (non-condensing) |
| MTBF | Over 1,000,000 hours |
| Dimensions | 4.53 in x 6.87 in x 1.02 in |
| Power Requirement | Standard NIM power |
| Warranty | Limited lifetime warranty |
| LED Indicators | Port status, Link activity |
| Environmental Standards | ROHS compliant |
| Safety Certifications | UL, CE Mark, IEC |
