C1-N3K-C3172TQ
Model: C1-N3K-C3172TQ – Cisco Nexus 3000 Series Platform
Details: Cisco ONE Nexus 3172T 48 x 1/10GBase-T and 6 QSFP+ ports
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
C1-N3K-C3172TQ Overview
Quick Specs Figure 1 shows the appearance of C1-N3K-C3172TQ.
Table 1 shows the Quick Specs.
| Brand | Cisco |
| Model | Nexus 3172T |
| Ports | 48 x 1/10GBase-T, 6 QSFP+ |
| Form Factor | 1 RU |
| Switching Capacity | 1.44 Tbps |
| Forwarding Rate | 1080 Mpps |
| Latency | Under 1 microsecond |
| Packet Buffer | 12 MB |
| MAC Addresses | 128,000 |
| VLAN IDs | 4096 |
| Jumbo Frames | 9216 bytes |
| Management Ports | 1 x RJ-45 serial console, 1 x 10/100/1000 management port |
| Flash Memory | 4 GB |
| SDRAM | 8 GB |
| Power Supply | Dual, hot-swappable, redundant |
| Environmental Operating Range | Temperature: 32??F to 104??F (0??C to 40??C), Humidity: 5% to 95% (non-condensing) |
| Dimensions (HxWxD) | 1.75 x 17.3 x 21.1 in (4.45 x 43.94 x 53.59 cm) |
| Fans | Hot-swappable, redundant |
| Operating System | Cisco NX-OS |
| MTBF | 836,380 hours |
| Warranty | Limited lifetime |
