C1-N5624Q
Model: C1-N5624Q – Cisco Nexus 5000 Series Platform
Details: Cisco ONE Nexus 5624Q VXLAN 1RU Chassis, 12x40G QSFP+
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
C1-N5624Q Overview
Quick Specs Figure 1 shows the appearance of C1-N5624Q.
Table 1 shows the Quick Specs.
| Brand | Cisco |
| Model | C1-N5624Q |
| Form Factor | 1RU |
| Interfaces | 12x 40G QSFP+ |
| Switching Capacity | 1.92 Tbps |
| Forwarding Rate | 1.44 Bpps |
| Buffer Size | 9 MB |
| Latency | under 1??s |
| Max VLANs | 4094 |
| Max MAC Addresses | 32,000 |
| Power Supply | Dual redundant, hot-swappable |
| Power Consumption | under 500W |
| Cooling | Front-to-back airflow |
| Operating Temperature | 32??F to 104??F (0??C to 40??C) |
| Storage Temperature | -40??F to 158??F (-40??C to 70??C) |
| Humidity | 5% to 95% (non-condensing) |
| Dimensions | 1.72 x 17.3 x 18 inches |
| MTBF | over 500,000 hours |
| Management | CLI, SNMP, RMON, Syslog |
| VXLAN Support | Yes |
| Warranty | Limited Lifetime Warranty |
