-5%
C8R08A
Model: C8R08A – HP StoreFabric SN6000B 16Gb Bundled Fibre Channel Switch
Details: HPE StoreFabric SN6000B 16Gb 48/24 Bundled Fibre Channel Switch
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
C8R08A Overview
Quick Specs Figure 1 shows the appearance of C8R08A.
Table 1 shows the Quick Specs.
| Brand | HPE |
| Model | C8R08A |
| Product Name | HPE StoreFabric SN6000B 16Gb 48/24 Bundled Fibre Channel Switch |
| Switch Type | Fibre Channel Switch |
| Data Rate | 16Gbps |
| Number of Ports | 48 primary, 24 activated |
| Form Factor | 1U Rack-Mountable |
| Port Speed | 16 Gbps, 8 Gbps, and 4 Gbps (auto-sensing) |
| ISL Trunking | Supported |
| Power Supply | AC Power Supply |
| Max Fabric Latency | 700 ns with no contention, cut-through routing |
| Scalability | Maximum of 8 switches |
| Management | Web Tools, CLI, SNMP v1/v3, Brocade Network Advisor |
| Security | DH-CHAP, FCAP switch authentication |
| Dimensions | Width: 435 mm, Depth: 406 mm, Height: 43 mm |
| Temperature Range | 0??C to 40??C (32??F to 104??F) |
| Humidity Range | 10% to 90% (non-condensing) |
| Warranty | Limited Lifetime |
| Interop Mode | Mode-1, Mode-2, and Mode-3 |
| Diagnostic Tools | POST and online/offline diagnostics, including RAS and Fabric Vision technologies |
| Compliance | RoHS, WEEE |
