Name: C9300X-12Y-E
SKU: C9300X-12Y-E
Price: 6238.65 USD
Availability: InStock

C9300X-12Y-E

Model: C9300X-12Y-E Switch
Details: Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Essentials
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

C9300X-12Y-E Overview

Quick Specs Figure 1 shows the appearance of C9300X-12Y-E.

Table 1 shows the Quick Specs.

Product Code	C9300X-12Y-E
Description	Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Essentials
Device Type	Switch – 12 ports – L3 – managed – stackable
Enclosure Type	Rack-mountable 1U
Subtype	25 Gigabit Ethernet
Ports	12 x 1/10/25 Gigabit SFP28
Performance	Switching capacity: 1000 Gbps ¦ Switching capacity with stacking: 2000 Gbps ¦ Forwarding rate: 744.04 Mpps ¦ Forwarding rate with stacking: 1488 Mpps
Capacity	IPv4 routing table entries: 39000 ¦ Flexible NetFlow entries: 64000 ¦ Direct IPv4 routes: 24000 ¦ Indirect IPv4 routes: 15000 ¦ IPv6 routing table entries: 19500 ¦ VLAN IDs: 4094 ¦ Switched virtual interfaces (SVIs): 1000 ¦ Multicast routing flow table: 8000 ¦ QoS scale entries: 4000 ¦ ACL scale entries: 5000 ¦ PVST instances: 300 ¦ STP Virtual Ports for PVST: 13000 ¦ STP Virtual Ports for MST: 13000 ¦ Routed ports: 448
MAC Address Table Size	32000 entries
Jumbo Frame Support	9198 bytes
Routing Protocol	OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Features	DHCP support, trunking, Syslog support, full duplex mode, Stateful switchover (SSO), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Non-Stop Routing (NSR), Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), Cisco StackWise-480 technology, Cisco StackPower technology, Flexible NetFlow (FNF), Multicast Source Discovery Protocol (MSDP), 802.1x authentication, 16MB packet buffer, FTP client, MACsec support, 3 fans, Control plane protection (CoPP), Virtual Extensible LAN (VXLAN), Application Visibility and Control (AVC), Source-Specific Multicast (SSM), integrated Wireshark, VLAN Double Tagging (Q-in-Q), Ethernet over MPLS (EoMPLS), Hierarchical Virtual Private LAN Service (H-VPLS), Private VLAN, Layer 3 VPN (L3VPN) support, Encapsulated Remote SPAN (ERSPAN), Security Group Tag (SGT) caching, Security Group Access Control List (SGACL), IT Service Management (ITSM) integration, third-party IP Address Management (IPAM) integration, Cisco StackWise-1T technology
Compliant Standards	CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, EN 300 386, TVCN 7317, VCCI V-3/2009 Class A, CAN/CSA-C22.2 No. 60950-1
RAM	16 GB
Flash Memory	16 GB
Status Indicators	Status
Interfaces	24 x 1/10/25GBase-X SFP28
Power Device	Internal power supply
Power Provided	715 Watt
Voltage Required	AC 120/230 V (50/60 Hz)
Width	17.5 in
Depth	16.1 in
Height	1.7 in
Service & Support	Limited warranty – replacement – lifetime – response time: next business day ¦ Technical support – consulting – 90 days
Min Operating Temperature	23 °F
Max Operating Temperature	113 °F
Humidity Range Operating	5 – 90% (non-condensing)
Min Storage Temperature	-40 °F
Max Storage Temperature	158 °F
Humidity Range Storage	5 – 90% (non-condensing)
