SG300-28MP Original price was: $301.00.Current price is: $285.95.

C9500-12Q-A

Original price was: $11,976.00.Current price is: $11,377.20.

Model: C9500-12Q-A – Cisco Switch Catalyst 9500
Details: Catalyst 9500 12-port 40G switch, Advantage
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

Add to quote
Add to compare
Add to wishlist
SKU: C9500-12Q-A Categories: , ,
Description

C9500-12Q-A Overview

Quick Specs Figure 1 shows the appearance of C9500-12Q-A.

Table 1 shows the Quick Specs.

Switching capacity Up to 960 Gbps
Forwarding rate Up to 720 Mpps
Total number of MAC addresses Up to 64,000*
Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes) Up to 64,000 indirect*Up to 32,000 host*
Total number of IPv6 routes Up to 32,000 indirect*Up to 16,000 host*
Multicast scale Up to 48,000*
QoS ACL scale Up to 18000*
Security ACL scale Up to 18000*
FNF entries Up to 512,000*
DRAM 16 GB
Flash 16 GB
VLAN IDs 4000
Total Switched Virtual Interfaces (SVIs) 4000
Jumbo frame 9198 bytes
Dimensions (H x W x D) 1.73 x 17.5 x 21.52 in
Rack units (RU) 1 RU
Input voltage 90 to 264 VAC
Operating temperature 32°F to 104°F (0° to 40°C)
Storage temperature -4° to 149°F (-20° to 65°C)
Relative humidity operating and nonoperating noncondensing Ambient (noncondensing) operating: 5% to 90%Ambient (noncondensing) nonoperating and storage: 5% to 95%
Altitude Operation up to 6000 ft
MTBF (hours) 179,660
Power Supply Feature Support in the Catalyst 9500 Series
AC power max rating 950W
System power consumption 850W max
Input-voltage range and frequency AC 115 to 230 VAC, 50 to 60 Hz
Power supply efficiency 94%
Total output BTU (Note: 1000 BTU/hr = 293W) 2901 BTU/hr (850W) max
Input current AC 10A at 115VAC, 5 A at 230VAC
Output ratings 12V at 79A, 12V at 3A
Output holdup time AC = 10 ms at maximum load
Power-supply input receptacles AC IEC 60320 C16
Power cord rating AC 15A
