CE12816-DC
Model: CE12816-DC Huawei CE12800 Series Data Center Switch
Details: CE12816 DC Assembly Chassis(with CMUs and Fans)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CE12816-DC Overview
Quick Specs Figure 1 shows the appearance of CE12816-DC.
Table 1 shows the Quick Specs.
| Switching Capacity(Tbit/s) | 178/1,032 |
| Forwarding Rate(Mpps) | 69,120 |
| Service Slots | 16 |
| Switching FabricModule Slots | 6 |
| Fabric Architecture | Clos architecture, cell switching, VoQ, and distributed large buffer |
| Airflow Design | Strict front-to-back |
| Device Virtualization | Virtual System (VS) |
| Network Virtualization | M-LAG |
| VM Awareness | Agile Controller |
| Network Convergence | FCoE |
| Data Center Interconnect | BGP-EVPN |
| Programmability | OpenFlow |
| Traffic Analysis | NetStream |
| VLAN | Adding access, trunk, and hybrid interfaces to VLANs |
| MAC Address | Dynamic learning and aging of MAC addresses |
| IP Routing | IPv4 routing protocols, such as RIP, OSPF, IS-IS, and BGP |
| IPv6 | IPv6 over VXLAN |
| Multicast | IGMP, PIM-SM, PIM-DM, MSDP, and MBGP |
| MPLS | Basic MPLS functions |
| Reliability | Link Aggregation Control Protocol (LACP) |
| QoS | Traffic classification based on Layer 2, Layer 3, Layer 4, and priority information |
| O&M | IEEE 1588v2 |
| Configurationand Maintenance | Console, Telnet, and SSH terminals |
| Securityand Management | 802.1x authentication |
| Dimensions(W x D x H, mm) | 442 x905 x1,597.4(36 U) |
| Chassis Weight (empty) | < 290 kg(639 lb) |
| Operating Voltage | AC: 90V to 290VDC: -38.4V to -72VHVDC: 240V |
| Max. Power Supply | 30,000W |
