CE6855-48T6Q-HI
Model: CE6855-48T6Q-HI – Huawei CloudEngine 6800 Data Center Switches
Details: CE6855-48T6Q-HI Switch(48-Port 10GE RJ45,6-Port 40GE QSFP+,Without Fan and Power Module).
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CE6855-48T6Q-HI Overview
Quick Specs Figure 1 shows the appearance of CE6855-48T6Q-HI.
Table 1 shows the Quick Specs.
| Item | Description |
| Processor | 1.2 GHz, quad-core |
| DRAM Memory | 2 GB |
| NOR Flash | 16 MB |
| NAND Flash | 1 GB |
| Mean time between failures (MTBF) | 54.48 years |
| Mean time to repair (MTTR) | 1.81 hours |
| Physical specifications | Dimensions (W x D x H): 442.0 mm x 600.0 mm x 43.6 mm (17.4 in. x 23.6 in. x 1.72 in.)Weight (with two power modules and two fan modules, calculated based on the heaviest model if multiple models are supported): 12.6 kg (27.78 lb) |
| Temperature | Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.)NOTE:When the altitude is 1800-5000 m (5096-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).Storage temperature: -40°C to +70°C (-40°F to +158°F) |
| Relative humidity | 5% RH to 95% RH, noncondensing |
| Altitude | < 5000 m (16404 ft.) |
| Noise (sound pressure, 27°C) | Back-to-front airflow: < 53 dBAFront-to-back airflow: < 53 dBA |
| Power source type | AC/DC/high-voltage DC |
| AC power input | Rated input voltage range: 100 V AC to 240 V AC, 50/60 HzMaximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz |
| DC power input | Rated voltage range: -48 V DC to -60 V DCMaximum voltage range: -38.4 V DC to -72 V DC |
| High-voltage DC power input | Rated voltage of 240 V high-voltage DC power input: 240 V DCMaximum voltage range of 240 V high-voltage DC power input: 188 V DC to 290 V DCRated voltage range of 380 V high-voltage DC power input: 240 V DC to 380 V DCMaximum voltage range of 380 V high-voltage DC power input: 188 V DC to 400 V DC |
| Rated input current | 600 W AC&240 V DC power module (PAC-600WB series): 8 A (100 V AC to 240 V AC)/4 A (240 V DC)600 W high-voltage DC power module (PHD-600WA series): 4 A (240 V DC to 380 V DC)1200 W DC power (PDC-1K2WA series): 38 A (-48 V DC to -60 V DC) |
| Maximum power consumption | 346 W |
| Typical power consumption | 219 W (100% throughput, 3 m Ethernet cables on 48 ports and QSFP+ cables on 6 ports, double power modules) |
| Maximum heat dissipation | 1181 BTU/hr |
| Typical heat dissipation | 747 BTU/hr (100% throughput, 3 m Ethernet cables on 48 ports and QSFP+ cables on 6 ports, double power modules) |
| Surge protection | Ethernet electrical ports: 2 kV in common modePower module:AC: 4 kV in common mode and 2.5 kV in differential modeDC: 4 kV in common mode and 2 kV in differential mode |
| Heat dissipation mode | Air cooling |
| Airflow | Front-to-back or back-to-front, depending on the fan modules and power modules |
| Power module backup | 1+1 backup |
| Fan module backup | 1+1 backup not supportedNOTE:A CE6800 chassis uses two fan modules, with each fan module containing two fans. The four fans in the chassis work in 3+1 backup mode. |
| Hot swap | Supported by all power modules and fan modules |
| Availability | 0.99999620929 |
| Service port supporting the stack function | 10GE electrical ports and 40GE optical ports |
