Sold out
CEX-L24CQJ
Model: Huawei CEX-L24CQJ
Details: CE16800-X
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
CEX-L24CQJ Overview
Quick Specs Figure 1 shows the appearance of CEX-L24CQJ.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | CEX-L24CQJ |
| Switching Capacity | 180 Tbps |
| Forwarding Performance | 7680 Mpps |
| Slot Capacity | 18 slots |
| Number of Line Cards | 18 |
| Number of Power Supply Slots | 4 |
| Number of Fan Slots | 3 |
| Maximum Port Density | 576x 100GE |
| Operating Temperature | 0??C to 45??C |
| Storage Temperature | -40??C to 70??C |
| Relative Humidity | 5% to 95% |
| Power Supply AC Input | 100V-240V AC |
| Power Supply DC Input | -38.4V to -72V DC |
| Typical Power Consumption | 9500W |
| MTBF | 200,000 hours |
| Dimensions (HxWxD) | 800 mm x 436 mm x 1100 mm |
| MAC Address Table Size | 1.28M |
| ARP Table Size | 384K |
| Routing Table Size | 192K |
| Security Features | 802.1X, NAC, RADIUS, TACACS+ |
