CFP-100G-SR10=
Model: CFP-100G-SR10= – Cisco 100 Gigabit Optical Modules
Details: 100GBASE-SR10 CFP transceiver, 100m OM3 MMF
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CFP-100G-SR10= Overview
Quick Specs Figure 1 shows the appearance of CFP-100G-SR10=.
Table 1 shows the Quick Specs.
| Description | Cisco 100GBASE-SR10 CFP Module for MMF (<100m OM3/< 150m OM4) |
| Dimensions | 144.8 x 82 x 13.6 mm |
| Wavelength (nm) | 850 |
| Fiber Type | MMF |
| Core Size (microns) | 5050 |
| Modal Bandwidth (MHz-km) | 2000 (OM3)4700 (OM4) |
| Max Distance | 100 m150 m |
| Digital Optical Monitoring (DOM) | NO |
| Average Transmit Power (dBm) | Max:-1.0 per laneMin:-7.6 per lane |
| Average Receive Power (dBm) | Max:2.4 per laneMin:-9.5 per lane |
| Transmit and Receive Wavelength | Ten lanes, 840 to 850 nm |
| Operating temperature | 32 and 158°F (0 to 70°C) |
| Storage temperature | -40 to 185°F (-40 to 85°C) |
| Maximum power consumption | 12 W |
