CFP-40G-FR=
Model: CFP-40G-FR= – Cisco 40 Gigabit Optical Modules
Details: CFP 40GBASE-FR optical transceiver module
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CFP-40G-FR= Overview
Quick Specs Figure 1 shows the appearance of CFP-40G-FR=.
Table 1 shows the Quick Specs.
| Description | Cisco multirate 40GBASE-FR and OTU3 VSR2000-3R2 CFP Module for SMF |
| Dimensions | 144.8 x 82 x 13.6 mm |
| Wavelength (nm) | 1550 |
| Cable Type | Single-mode fiber (SMF) |
| Core Size (microns) | G.652 |
| Modal Bandwidth (MHz-km) | |
| Cable Distance | 2km |
| Type | 40GBASE-FR and OTU3 VSR2000-3R2 |
| Transmit Power (dBm)* | Max:3.0 per laneMin:0.0 per lane |
| Receive Power (dBm)* | Max:3.0 per laneMin:-6.0 per lane |
| Transmit and Receive Wavelength (nm) | 1530 to 1565 |
| Operating temperature | 0 to 70°C (32 to 158°F) |
| Storage temperature | -40 to 85°C (-40 to 185°F) |
| Power consumption | up to 8W per 40G CFP port |
