CFP40-1331-10-LC
Model: Huawei CFP40-1331-10-LC 02310TMD 40G Single-mode Optical Module
Details: 40G Single-mode Optical Module, CFP, 1331nm, 10km, LC
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CFP40-1331-10-LC Overview
Quick Specs Figure 1 shows the appearance of CFP40-1331-10-LC.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | CFP40-1331-10-LC |
| Form Factor | CFP |
| Transmission Speed | 40Gbps |
| Wavelength | 1331nm |
| Interface | LC Connector |
| Fiber Type | Single-mode |
| Maximum Distance | 10km |
| Operating Temperature Range | 0°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Power Supply Voltage | 3.3V |
| Power Consumption | Less than 8W |
| RoHS Compliant | Yes |
| Digital Diagnostic Monitoring | Yes |
| Maximum Data Rate | 41.25Gbps |
| Tunable Wavelength | Fixed |
| EMC Compliance | Class A |
| Humidity | 5% to 95% non-condensing |
| MTBF | Over 2 million hours |
| Application | Data center, enterprise core, and distribution networks |
