-5%
CP-7821-K9
Model: CP-7821-K9 Cisco UC Phone 7821
Details: Cisco IP Phone 7821
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CP-7821-K9 Overview
Quick Specs Figure 1 shows the appearance of CP-7821-K9.
Table 1 shows the Quick Specs.
| Signaling protocol support | ● Session Initiation Protocol (SIP) |
| Codec support | ● G.711a/μ, G.722, G.729a, iLBC |
| Key call features support | ● + Dialing (E.164)● Abbreviated dial● Adjustable ringing and volume levels● Adjustable display contrast● Agent greeting● Auto-answer● Auto-detection of headset (Not available on the IP Phone 7811)● Busy Lamp Field (BLF) (Not available on the IP Phone 7811)● Call back● Call forward● Call history● Call park● Call Pickup● Call timer● Call waiting● Caller ID● cBarge● Corporate directory● Conference● Cross Cluster Extension Mobility (EMCC)● Dial from the list● Direct transfer● Do not disturb● Extension Mobility (EM)● Forced access codes and client matter codes● Group call pickup● Hold/resume● Immediate divert● Intercom (Not available on the IP Phone 7811)● Join (Not available on the IP Phone 7811)● Message-waiting indicator● Meet me conference● Mobility● Music on hold● Mute● Network profiles (automatic)● On- and off-network distinctive ringing● Personal directory● Privacy● Private Line Automated Ringdown (PLAR)● Redial● Ring tone per line appearance● Shared line● Silent monitoring and recording● Speed dial● Time and date display● Transfer● Voicemail● Whisper coaching |
| Language support | ● Arabic (Arabic Area)● Bulgarian (Bulgaria)● Catalan (Spain)● Chinese (China)● Chinese (Hong Kong)● Chinese (Taiwan)● Croatian (Croatia)● Czech (Czech Republic)● Danish (Denmark)● Dutch (Netherlands)● English (United Kingdom)● Estonian (Estonia)● French (France)● Finnish (Finland)● German (Germany)● Greek (Greece)● Hebrew (Israel)● Hungarian (Hungary)● Italian (Italy)● Japanese (Japan)● Latvian (Latvia)● Lithuanian (Lithuania)● Korean (Korea Republic)● Norwegian (Norway)● Polish (Poland)● Portuguese (Portugal)● Portuguese (Brazil)● Romanian (Romania)● Russian (Russian Federation)● Spanish (Columbia)● Spanish (Spain)● Slovak (Slovakia)● Swedish (Sweden)● Serbian (Republic of Serbia)● Serbian (Republic of Montenegro)● Slovenian (Slovenia)● Thai (Thailand)● Turkish (Turkey) |
| Multiple ring tones | ● The phone supports user-adjustable ring tones. |
| Directories | ● The phone identifies incoming messages and categorizes them for users on the screen.This makes it fast and easy to return calls using direct dial-back capability. The corporatedirectory integrates with the Lightweight Directory Access Protocol (LDAP) standard directory. |
| Quality-of-service (QoS) options | ● The phone supports CDP and 802.1Q/p standards, and can be configured with an801.1Q VLAN header containing the VLAN ID overrides configured by the Admin VLAN ID. |
| Security | ● Certificates● Image authentication● Device authentication● File authentication● Signaling authentication● Media encryption using Secure Real-Time Transfer Protocol (SRTP) using AES-128● Signaling encryption using Transport Layer Security (TLS) Protocol using AES-128 or AES-256● Encrypted configuration files● 802.1X authentication● Cryptography |
| Configuration options | ● The user can configure IP address assignment statically or through the DHCP client. |
| Physical dimensions (H×W×D) | ● IP Phone 7821: 207 x 206 x 28mm (exclude foot stand) |
| Weight | ● IP Phone 7821: 867g |
| Display | ● IP Phone 7821: 3.5” 396×162 pixels |
| Ethernet switch | ● The phone has a 10/100BASE-T or a 10/100/1000BASE-T |
| Phone casing composition | ● Polycarbonate acrylonitrile butadiene styrene (ABS) textured plastic. |
| Power requirements | ● The phone is an interoperable IEEE 802.3af PoE (Class 1 device); 48 VDC is required;it can be supplied locally at the desktop using an optional AC-to-DC power supply (CP-PWR-CUBE-3=).Use of the power supply also requires the use of one of the corresponding AC country cords. |
| Operational temperature | ● 32 to 104°F (0 to 40°C) |
| Nonoperational temperature shock | ● 14 to 140°F (-10 to 60°C) |
| Humidity | ● Operating 10% to 90%, non-condensing● Non-operating 10% to 95%, non-condensing |
| Cosmetic | ● Cisco cosmetic class A |
| Certification and compliance | ● Regulatory Compliance◦ CE Markings per directives 2004/108/EC and 2006/95/EC● Safety◦ UL 60950 Second Edition◦ CAN/CSA-C22.2 No. 60950 Second Edition◦ EN 60950 Second Edition (including A11 & A12)◦ IEC 60950 Second Edition (including A11 & A12)◦ AS/NZS 60950◦ GB4943● EMC – Emissions◦ 47CFR Part 15 (CFR 47) Class B◦ AS/NZS CISPR22 Class B◦ CISPR22: 2005 w/Amendment 1: 2005 Class B◦ EN55022: 2006 w/Amendment 1: 2007 Class B◦ ICES003 Class B◦ VCCI Class B◦ EN61000-3-2◦ EN61000-3-3◦ KN22 Class B● EMC – Immunity◦ EN55024◦ CISPR24◦ EN60601-1-2◦ KN24◦ Armadillo Light● Telecom◦ FCC Part 68 HAC◦ CS-03-HAC◦ AS/ACIF S004◦ AS/ACIF S040◦ NZ PTC 220◦ Industry Standards: TIA 810 and TIA 920◦ Industry Standards: IEEE 802.3 Ethernet, IEEE 802.3af and 802.3at |
