-5%
CR5DL2XEFG7A
Model: Huawei NetEngine NE40E Series Router Processing Unit CR5DL2XEFG7A
Details: 2-Port 10GBase LAN/WAN-SFP+ + 24-Port 100/1000Base-X-SFP Integrated Line Processing Unit (LPUI-51)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CR5DL2XEFG7A Overview
Quick Specs Figure 1 shows the appearance of CR5DL2XEFG7A.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | CR5DL2XEFG7A |
| Ports | 2-Port 10GBase LAN/WAN-SFP+ + 24-Port 100/1000Base-X-SFP |
| Type | Integrated Line Processing Unit (LPUI-51) |
| Form Factor | 1U |
| Network Protocols | IPv4, IPv6 |
| Data Transfer Rate | 10/100/1000 Mbps |
| Connector Type | SFP+ |
| Supported SFP Modules | 10GBase, 1000Base |
| MAC Address Table | 32K entries |
| Jumbo Frame Support | Yes, up to 9K bytes |
| VLAN Support | Yes, up to 4K VLANs |
| Power Supply | AC 110/240V |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 70°C |
| Humidity | 10% to 90% (non-condensing) |
| Dimensions | 440 x 420 x 44 mm |
| LED Indicators | Power, Status, Network |
| MTBF | >100,000 hours |
| Compliance | CE, FCC, RoHS |
| Cooling | 2x internal fans |
