CWDM-SFPGE-1511
Model: Huawei CWDM-SFPGE-1511 Optical Transceiver
Details: CWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1511nm,80km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CWDM-SFPGE-1511 Overview
Quick Specs Figure 1 shows the appearance of CWDM-SFPGE-1511.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | CWDM-SFPGE-1511 |
| Product Type | CWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1511nm |
| Maximum Distance | 80km |
| Connector Type | LC |
| Technology | Single-Mode |
| Transmit Power | -1 to +3 dBm |
| Receive Sensitivity | -24 dBm |
| Operating Temperature | -5°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Digital Diagnostics | Yes |
| Compliance Standards | RoHS, SFP MSA |
| Power Consumption | < 1.5W |
| Dimensions | 56.5mm x 13.4mm x 8.5mm |
| Protocol | Gigabit Ethernet |
| Compatibility | Multi-vendor equipment |
| MTBF | 1,000,000 hours |
