CWDM-SFPGE-1611
Model: Huawei CWDM-SFPGE-1611 Optical Transceiver
Details: CWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1611nm,80km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CWDM-SFPGE-1611 Overview
Quick Specs Figure 1 shows the appearance of CWDM-SFPGE-1611.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model Name | CWDM-SFPGE-1611 |
| Product Type | CWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5 Gbps |
| Optical Mode | Single-mode |
| Wavelength | 1611 nm |
| Transmission Distance | 80 km |
| Connector Type | LC |
| Power Supply Voltage | 3.3 V |
| Receiver Sensitivity | -28 dBm |
| Operating Temperature Range | 0°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Maximum Supply Current | 300 mA |
| Compliance | CMIS |
| Signal Loss | <2.0 dB |
| Humidity Range | 5% to 95% (non-condensing) |
| Regulatory Standards | RoHS, FCC |
| EMC Standards | EN 55022, EN 55024 |
| MTBF | 1,000,000 hours |
