CXP-100G-SR12
Model: CXP-100G-SR12 – Cisco 100 Gigabit Optical Modules
Details: CXP form factor, 100GBASE-SR10 compliant, no breakout
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
CXP-100G-SR12 Overview
Quick Specs Figure 1 shows the appearance of CXP-100G-SR12.
Table 1 shows the Quick Specs.
| Description | 100GBASE-SR10 CXP Module for MMF |
| Dimensions | 13.3 x 24 x 62 mm (0.52 x 0.94 x 2.44 in) |
| Wavelength (nm) | 850 |
| Cable Type | MMF |
| Core Size (Microns) | 50.050.0 |
| Modal Bandwidth (MHz*km)*** | 2000 (OM3)4700 (OM4) |
| Cable Distance* | 100m150m** |
| Type | 100GBASE-SR10 |
| Transmit Power (dBm)* | Max:2.5 per laneMin:-7.6 per lane |
| Receive Power (dBm)* | Max:2.4 per laneMin:-9.5 per lane |
| Transmit and Receive Center Wavelength Range (nm) | 12 lanes:840 to 860 nm |
| Storage temperature | -40 to 185°F (-40 to 85°C) |
| CXP operating temperature | 0 to 70°C (32 to 158°F) |
| CXP power consumption | At 70°C: <3.5W maximum |
