DC12-100
Model: DC12-100 – Dahua Cameras Accessories
Details: Dahua Lead Acid Battery
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
DC12-100 Overview
Quick Specs Figure 1 shows the appearance of DC12-100.
Table 1 shows the Quick Specs.
| Brand | Dahua |
| Model | DC12-100 |
| Type | Lead Acid Battery |
| Nominal Voltage | 12V |
| Capacity | 100Ah |
| Terminal Type | T12 |
| Dimensions (L x W x H) | 330 x 171 x 220 mm |
| Operating Temperature Range | -20°C to 50°C |
| Charging Temperature Range | 0°C to 40°C |
| Discharge Temperature Range | -20°C to 50°C |
| Storage Temperature Range | -20°C to 40°C |
| Cycle Life | 500 cycles |
| Self Discharge | Less than 3% per month |
| Max Discharge Current | 1000A (5s) |
| Internal Resistance | ° 5.0 m° |
| Float Charging Voltage | 13.5-13.8V |
| Cycle Charging Voltage | 14.4-15.0V |
| Container Material | ABS (Option: Flame Retardant V0) |
| Terminal Material | Copper |
| Application | Solar System, UPS, Telecommunication |
