DC12-150
Model: DC12-150 – Dahua Cameras Accessories
Details: Dahua Lead Acid Battery
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
DC12-150 Overview
Quick Specs Figure 1 shows the appearance of DC12-150.
Table 1 shows the Quick Specs.
| Brand | Dahua |
| Model | DC12-150 |
| Battery Type | Lead Acid Battery |
| Nominal Voltage | 12V |
| Capacity | 150Ah |
| Dimension (L x W x H) | 330mm x 172mm x 215mm |
| Nominal Operating Temperature | -20°C to 50°C |
| Storage Temperature | -20°C to 50°C |
| Cycle Life | 600 cycles at 50% DOD |
| Terminal Type | F10 |
| Max Charging Current | 45A |
| Standard Charging Current | 15A |
| Self Discharge Rate | Less than 3% per month |
| Application Use | UPS, Solar, Telecommunications |
| Certification | ISO9001, CE |
| Internal Resistance | Approx. 4.5m° |
| Design Life | 10 – 12 years |
| Case Material | ABS (UL94:HB, UL94:V0 Optional) |
| Float Charging Voltage | 13.5V – 13.8V |
| Equalization Charging Voltage | 14.1V – 14.4V |
| Usage | Deep Cycle |
