DVR-104G-F1
Model: DVR-104G-F1 – Hikvision HiLook Turbo HD Products
Details: 4-ch 1080p Mini 1U Lite H.264 DVR
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
DVR-104G-F1 Overview
Quick Specs Figure 1 shows the appearance of DVR-104G-F1.
Table 1 shows the Quick Specs.
| Brand | Hikvision |
| Product Name | DVR-104G-F1 |
| Channels | 4 |
| Max Recording Resolution | 1080p |
| Compression Format | H.264 |
| Video Output | HDMI/VGA |
| Recording Frame Rate | Up to 30 fps at 1080p resolution |
| Playback Resolution | 1080p, 720p, VGA, WD1, 4CIF, CIF |
| Network Interface | 1 RJ-45 10/100 Mbps Ethernet port |
| USB Interface | 2 ?? USB 2.0 ports |
| HDD Interface | 1 SATA interface |
| Max Storage Capacity | Up to 6 TB capacity for each disk |
| Power Supply | 12 VDC |
| Power Consumption (without HDD) | ?? 8 W |
| Operating Temperature | -10 ??C to +55 ??C (14 ??F to +131 ??F) |
| Operating Humidity | 10% to 90% |
| Dimensions (W ?? D ?? H) | 315 ?? 242 ?? 45 mm (12.4 ?? 9.53 ?? 1.77 inch) |
| Video Bit Rate | 32 Kbps to 6 Mbps |
| Audio Bit Rate | 64 Kbps |
| Protocol Support | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP?, HTTPS |
| Motion Detection | Yes |
| Remote Viewing | Yes, via Hik-Connect app |
