DWDM-SFPGE-1531-12
Model: Huawei 2.5G Single-mode Optical Transceiver DWDM-SFPGE-1531-12
Details: DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1531.12nm,120km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
DWDM-SFPGE-1531-12 Overview
Quick Specs Figure 1 shows the appearance of DWDM-SFPGE-1531-12.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | DWDM-SFPGE-1531-12 |
| Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1531.12nm |
| Distance | 120km |
| Cable Type | Single-mode |
| Connector | LC |
| Transmit Power | 0 to +5 dBm |
| Receiver Sensitivity | -24 dBm |
| Temperature Range | -40°C to +85°C |
| Voltage Range | 3.3V |
| Diagnostics | Digital Diagnostics Monitoring (DDM) |
| Compliance | MSA Compliant |
| Power Consumption | < 1.5W |
| Fiber Type | Singlemode Fiber (SMF) |
| Humidity Range | 5% to 95% (non-condensing) |
| Mounting Type | Plug-in |
| Bit Error Rate (BER) | 10^-12 |
| Application | Metro/Access Networks |
| Protocol | ITU-T G.694.1 |
