DWDM-SFPGE-1536-61
Model: Huawei DWDM-SFPGE-1536-61 Optical Transceiver
Details: DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1536.61nm,120km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
DWDM-SFPGE-1536-61 Overview
Quick Specs Figure 1 shows the appearance of DWDM-SFPGE-1536-61.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Product Name | DWDM-SFPGE-1536-61 |
| Form Factor | eSFP |
| Data Rate | 2.5 Gbps |
| Wavelength | 1536.61 nm |
| Optical Fiber Type | Single-mode |
| Transmission Distance | 120 km |
| Connector Type | LC |
| Temperature Range | -40°C to +85°C |
| Power Supply Voltage | 3.3V |
| TX Power | -1 to +3 dBm |
| Receiver Sensitivity | -34 dBm |
| Protocols | ITU-T G.694.1 |
| Digital Diagnostics | Yes |
| Modulation | NRZ |
| Housing Material | Metal |
| Compliance | RoHS |
| MTBF | 1,000,000 hours |
| Speed Compatibility | 2.5G, 2G, 1G |
| Application | 10G Ethernet, SDH, SONET |
