DWDM-SFPGE-1539-77
Model: Huawei DWDM-SFPGE-1539-77 Optical Transceiver
Details: DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1539.77nm,120km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
DWDM-SFPGE-1539-77 Overview
Quick Specs Figure 1 shows the appearance of DWDM-SFPGE-1539-77.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Product Name | DWDM-SFPGE-1539-77 |
| Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1539.77nm |
| Transmission Distance | 120km |
| Connector Type | LC |
| Optical Output Power | -1 ~ 4 dBm |
| Receiver Sensitivity | -34 dBm |
| Transmission Medium | Single-mode Fiber |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Power Supply Voltage | 3.3V |
| Power Consumption | < 1W |
| EMC Standards | FCC Part 15 Class B, and CISPR 22 Class B |
| Humidity | 5% – 95% (non-condensing) |
| MTBF | > 1,000,000 hours |
| Protocols | IEEE 802.3 |
| RoHS Compliance | Yes |
| Digital Diagnostics Monitoring (DDM) | Supported |
| Hot Pluggable | Yes |
