-5%
DWDM-SFPGE-1540-56
Model: Huawei DWDM-SFPGE-1540-56 Optical Transceiver
Details: DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1540.56nm,120km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
DWDM-SFPGE-1540-56 Overview
Quick Specs Figure 1 shows the appearance of DWDM-SFPGE-1540-56.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Product Name | DWDM-SFPGE-1540-56 |
| Optical Wavelength | 1540.56nm |
| Application | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Cable Fiber Type | Single-mode |
| Maximum Distance | 120 km |
| Connector Type | LC |
| Power Consumption | <1.5W |
| Operating Temperature Range | -40 to 85°C |
| Storage Temperature Range | -40 to 85°C |
| Transmission Distance | Up to 120 km |
| Digital Diagnostic Monitoring (DDM) | Yes |
| Modulation Format | NRZ |
| Transmitter Power | -1 to 2 dBm |
| Receiver Sensitivity | -24 dBm |
| Electrical Interface | LC |
| Compliance | SFP MSA, RoHS |
| MTBF | >1,000,000 hours |
