DWDM-SFPGE-1541-35
Model: Huawei DWDM-SFPGE-1541-35 Optical Transceiver
Details: DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1541.35nm,120km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
DWDM-SFPGE-1541-35 Overview
Quick Specs Figure 1 shows the appearance of DWDM-SFPGE-1541-35.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | DWDM-SFPGE-1541-35 |
| Transceiver Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1541.35nm |
| Cable Type | Single-mode |
| Maximum Distance | 120km |
| Connector | LC |
| Operating Temperature | -5°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Power Consumption | 1.5W Max |
| Digital Diagnostics | Yes |
| Compliance | RoHS, MSA Compliant |
| TX Power | -1 to +4 dBm |
| Receiver Sensitivity | -23 dBm |
| Extinction Ratio | 9 dB |
| Dispersion Penalty | 2 dB |
| Modulation Format | NRZ |
| Regulatory Approvals | FCC, CE, TUV, UL |
