DWDM-SFPGE-1543-73
Model: Huawei DWDM-SFPGE-1543-73 Optical Transceiver
Details: DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1543.73nm,120km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
DWDM-SFPGE-1543-73 Overview
Quick Specs Figure 1 shows the appearance of DWDM-SFPGE-1543-73.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Product Name | DWDM-SFPGE-1543-73 |
| Transceiver Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Fiber Type | Single-mode |
| Wavelength | 1543.73nm |
| Maximum Distance | 120km |
| Connector | LC |
| Transmit Power | 0 to +5 dBm |
| Receiver Sensitivity | -23 dBm |
| Power Supply | 3.3V |
| Power Consumption | <1.5W |
| Digital Diagnostics | Yes |
| Temperature Range | -40 to 85°C |
| Compliance | RoHS |
| Form Factor Compliance | SFF-8472 |
| MTBF | 1,000,000 hours |
| Modulation Format | NRZ |
| Security Feature | SDN Compatible |
| Application | Telecom and Data Center |
