ES-10X
Model: ES-10X – Ubiquiti Enterprise Switches Series
Details: Ubiquiti / UBNT Networks EdgeSwitch 8-Port Managed Switch, 10G Ethernet, 2 SFP, POE, Enterprise
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
ES-10X Overview
Quick Specs Figure 1 shows the appearance of ES-10X.
Table 1 shows the Quick Specs.
| Model | ES-10X |
| Brand | Ubiquiti / UBNT Networks |
| Type | Managed Switch |
| Ports | 8-Port 10G Ethernet |
| SFP Ports | 2 |
| Power Over Ethernet (POE) | Yes |
| Management Type | Enterprise |
| Networking Standards | IEEE 802.3af/at, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Layer | Layer 2 |
| Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.88 Mpps |
| Power Supply | External AC/DC Adapter |
| Input Voltage | 100-240VAC, 50/60 Hz |
| Maximum Power Consumption | 8W (excluding POE Output) |
| POE Budget | 150W |
| Operating Temperature | -10 to 50��C (14 to 122��F) |
| Operating Humidity | 5 to 95% Non-condensing |
| Mounting | Wall, Rackmount (Brackets Included) |
| Dimensions | 235 x 90 x 45 mm |
| Product Line | EdgeSwitch |
| Features | Layer-2 switching, VLAN, Auto-negotiation, Network monitoring, Traffic shaping |
