FDLCUPC03
Model: Huawei FDLCUPC02 14130643 Optical Cable Assembly
Details: Optical Cable Parts,DLC/UPC,DLC/UPC,single mode,30m,2 cores,0.03m/0.34m,GYFJH-2G.657A2,7.0mm,2mm,LSZH,Armored branch
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
FDLCUPC03 Overview
Quick Specs Figure 1 shows the appearance of FDLCUPC03.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | FDLCUPC03 |
| Product Type | Optical Cable Parts |
| Connector Type 1 | DLC/UPC |
| Connector Type 2 | DLC/UPC |
| Mode | Single Mode |
| Length | 30m |
| Cores | 2 Cores |
| Min. Bend Radius (Dynamic) | 0.03m |
| Min. Bend Radius (Static) | 0.34m |
| Cable Type | GYFJH-2G.657A2 |
| Outer Diameter | 7.0mm |
| Branch Cable Diameter | 2mm |
| Sheath Material | LSZH (Low Smoke Zero Halogen) |
| Armored | Yes, Armored Branch |
| Operating Temperature | -40°C to 70°C |
| Storage Temperature | -50°C to 85°C |
| Installation Temperature | -20°C to 60°C |
| Tensile Strength (Dynamic) | 600 N |
| Tensile Strength (Static) | 300 N |
| Crush Resistance | 1000 N/10cm |
