FG-61E-BDL
Model: FG-61E-BDL – FortiGate 61E Firewall with Bundle
Details: FG-61E Hardware plus 1 year 8×5 FortiCare and FortiGuard Unified (UTP) Protection
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
FG-61E-BDL Overview
Quick Specs Figure 1 shows the appearance of FG-61E-BDL.
Table 1 shows the Quick Specs.
| GE RJ45 WAN / DMZ Ports | 2 / 1 |
| GE RJ45 Internal Ports | 7 |
| GE RJ45 PoE/+ Ports | |
| Wireless Interface | |
| USB Ports | 1 |
| Console (RJ45) | 1 |
| Internal Storage | 1x 128 GB SSD |
| IPS Throughput | 2,400 Mbps |
| NGFW Throughput | 2,4250 Mbps |
| Threat Protection Throughput | 2, 5200 Mbps |
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 3 / 3 / 3 Gbps |
| Firewall Latency (64 byte UDP Packets) | 3μs |
| Firewall Throughput (Packet per Second) | 4.5 Mpps |
| Concurrent Sessions (TCP) | 1.3 Million |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput (512 byte) | 2 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 500 |
| SSL-VPN Throughput | 150 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 200 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 135 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 135 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 75,000 |
| Application Control Throughput (HTTP 64K) | 650 Mbps |
| CAPWAP Throughput (HTTP 64K) | 890 Mbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 16 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 30 / 10 |
| Maximum Number of FortiTokens | 500 |
| Maximum Number of Registered FortiClients | 200 |
| High Availability Configurations | Active / Active, Active / Passive,Clustering |
| Height x Width x Length | 1.5 x 8.5 x 6.3 inches38 x 216 x 160 mm |
| Form Factor | Desktop |
| Power Required | 100–240V AC, 50–60 Hz |
| Maximum Current | 115V AC / 0.9Â A, 230V AC / 0.6Â A |
| Total Available PoE Power Budget | N/A |
| Power Consumption (Average / Maximum) | 11.9Â / 14.3Â W |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -31–158°F (-35–70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | Fanless 0 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
