ICX7150-24-4X1G
Model: ICX7150-24-4X1G – Ruckus ICX7150 Switches
Details: ICX7150-24-4X1G is the 24-Port Entry-Level Enterprise-Class Stackable Access Switch.
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
ICX7150-24-4X1G Overview
Quick Specs Figure 1 shows the appearance of ICX7150-24-4X1G.
Table 1 shows the Quick Specs.
| Product Name | ICX7150 Switch 24x Geth PT 4X1G |
| Product Type | Ethernet Switch |
| RAM | 1GB |
| Manageable | Yes |
| Ethernet Technology | Gigabit Ethernet10 Gigabit Ethernet |
| Number of Total Expansion Slots | 8 |
| Product Family | ICX 7150 |
| Stack Port | Yes |
| Media Type Supported | Twisted PairOptical Fiber |
| Total Number of Network Ports | 24 |
| Redundant Power Supply Supported | No |
| Expansion Slot Type | SFP+ |
| Form Factor | Rack-mountableDesktop |
| Power Source | Power Supply |
| Layer Supported | 3 |
| Compatible Rack Unit | 1U |
| Number of SFP Slots | 4 |
| Number of SFP+ Slots | 4 |
| Modular | Yes |
| Uplink Port | Yes |
| Port / Expansion Slot Details | 24 x Gigabit Ethernet Network2 x Gigabit Ethernet Uplink4 x 10 Gigabit Ethernet Expansion Slot4 x Gigabit Ethernet Expansion Slot |
| Type | Internal power supply |
| Installed Qty | 1 |
| Power Provided | 36 watt |
| Max Supported Qty | 1 |
| Nominal Voltage | AC 120/230 V |
| Frequency Required | 50/60 hertz |
| PoE Power Budget (max) | 740W |
| Height | 1.7″ |
| Width | 17.3″ |
| Depth | 11″ |
| Product Series | ICX 7150 |
| Network Technology | 10/100/1000Base-T10GBase-X |
| Min Operating Temperature | 23 degree Fahrenheit |
| Max Operating Temperature | 122 degree Fahrenheit |
| Min Storage Temperature | -13 degree Fahrenheit |
| Max Storage Temperature | 158 degree Fahrenheit |
| Humidity Range Operating | 5 – 95% (non-condensing) |
| Humidity Range Storage | 0 – 95% (non-condensing) |
