ICX8200-24F
Model: Ruckus ICX8200-24F
Details: ICX8200
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
ICX8200-24F Overview
Quick Specs Figure 1 shows the appearance of ICX8200-24F.
Table 1 shows the Quick Specs.
| Brand | Ruckus |
| Model | ICX8200-24F |
| Ports | 24 Gigabit SFP Ports, 4 10G SFP+ Ports |
| Switching Capacity | 220 Gbps |
| Forwarding Rate | 164 Mpps |
| VLAN IDs | 4,096 |
| Jumbo Frames | Up to 9,000 bytes |
| Power Supply | Dual, Internal |
| Power Consumption | 90W max |
| Mounting | Rack-Mountable |
| Operating Temperature | 0??C to 40??C |
| Storage Temperature | -40??C to 70??C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (WxDxH) | 440mm x 330mm x 44mm |
| MAC Address Table | 32,000 entries |
| Quality of Service (QoS) | 8 Queues per Port |
| Layer2 Features | VLAN, STP, LACP |
| Layer3 Features | OSPF, RIP, PIM |
| Security | ACLs, Port Security |
| Management | CLI, Web, SNMP |
| Warranty | Limited Lifetime |
