Model: Huawei IPC6311-IR(4mm) 1.3MP Network IR Dome Camera
Details: Huawei IPC6311-IR(12mm) 1.3MP Network IR Dome Camera(30fps,f=12mm,FE,IR 30m)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

Add to quote
Add to compare
Add to wishlist
SKU: IPC6311-IR(12mm) Categories: , ,
Description

IPC6311-IR(12mm) Overview

Quick Specs Figure 1 shows the appearance of IPC6311-IR(12mm).

Table 1 shows the Quick Specs.

Image sensor 1/3″ 1.3 Megapixel Progressive Scan CMOS
Max. Image Resolution 1280(H)× 960(V)
Min. IlluminationDay &Night Mode 0.01 Lux @(F1.2,AGC ON), 0 Lux with IRAuto(ICR)/ Color / B/W /Timing/ Alarm Trigger
IR Distance 20~30m
Electronic shutter speedGain control 1/3 ~ 1/100,000sSupported
White balanceWide Dynamic Range MWB/AWB1/Locked WB/Fluorescent Lamp/incandescent Lamp/Warm Light Lamp/Natural LightSupported
Backlight compensation Supported
Lens mount ø14
Focal lengthMax. aperture ratio 4mm,12mm fixed lens optionalF2.0
Horizontal Angle of View IPC6311-IR(4mm): 73.1°, IPC6311-IR(12mm): 22°
Angle Adjustment range Pan: 0°~ 355°, Tilt: 0°~ 75°, Rotation: 0°~ 355°
Image Compression H.264 Main Profile,MJPEG
Video resolution and frame rateVideo Bitrate 50Hz: 25fps (1280 × 960), 25fps (1280 × 720)60Hz: 30fps (1280 × 960), 30fps (1280 × 720)32Kbps ~ 12Mbps
Multiple streamsMTU Configuration Dual streams (Main Stream/Sub Stream)Default: 1500; configuration range: 1280 ~ 1500
IP Address Filtering Supported
Communication interfaceAlarm interface 1 RJ45 10M/100M adaptable Ethernet interface,1 RS-485 interface(PELCO-P/D)1 alarm input /1alarm output
Audio Communication Voice intercom(Pick-up is needed), voice broadcasting, channel associated voice
Audio interfaceMotion detection 1-channel audio input/1-channel audio OutputSupported
Privacy maskingCorridor Format SupportedSupport aspect ratio 9:16
PU Access Protocol ONVIF 2.2
Network protocolBitrate Type ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, BonjourConstant bit rate (CBR), Variable Bit Rate (VBR)
ROI encoding Supported
Storage interfaceDigital watermark Micro SD/SDHC /SDXC card (64G)Supported
Security MeasuresFront-end Recording User name and password authentication, and support 802.1xSupport SD card schedule recording, alarm recording, and local playback
Alarm linkage Alarm Trigger: motion detection, tampering alarm, switch Input. Alarm action: switch output, SD card recording, notification on client, sending E-mail
Fast configurationMax. Video Stream Accessing Support indoor/outdoor scene switchSupport max. 6 channels video streams accessing
Web Browser IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +, support multi-language;Windows XP, Windows7, Windows8
Power supplyPower consumptionOperating temperature / humidity DC12V±10% / PoE(802.3af)5.5W MAXOperating temperature: -30ºC ~ 60ºCOperating humidity: 5% ~ 90% (Non-condensing)
Weather proof rating IP66
Vandal–proof LevelNet weight IEC60068-2-75 Testing,Eh,50J;EN50102,IK10800g
Physical Product Appearances ø139.9×99.9mm
