JH394A
Model: JH394A – HPE FlexFabric 5940 Switches
Details: HPE FlexFabric 5940 48XGT 6QSFP+ Switch
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
JH394A Overview
Quick Specs Figure 1 shows the appearance of JH394A.
Table 1 shows the Quick Specs.
| Product Name | HPE FlexFabric 5940 48XGT 6QSFP+ Switch |
| Brand | HPE |
| Product Model | JH394A |
| Form Factor | 1U Height |
| Ports | 48 x 1/10GBASE-T and 6 x 40GbE QSFP+ or 4 x 100GbE QSFP28 |
| Throughput | Up to 1440 Mpps |
| Switching Capacity | Up to 2.56 Tbps |
| MAC Address Table Size | 288K entries |
| Memory | 4 GB |
| Flash Memory | 1 GB |
| Latency | 1 °s |
| Management Features | IMC – Intelligent Management Center, SNMP, RMON, sFlow, CLI |
| Power Supply | 1+1 redundant hot-pluggable power supplies |
| Power Consumption | Max. 450W |
| Input Voltage | 100-240VAC |
| Routing/Switching Capacity | Layer 2 and Layer 3 |
| Quality of Service (QoS) | Advanced QoS features |
| Virtualization | Supports VXLAN and NVGRE |
| Security Features | Access control lists (ACL), IEEE 802.1X, and more. |
| Dimensions (W x D x H) | 17.32 x 26.02 x 1.72 in (43.99 x 66.06 x 4.37 cm) |
| Operating Temperature | 32°F to 113°F (0°C to 45°C) |
| Humidity Range Operating | 10% to 90%, non-condensing |
| Certifications | UL 60950-1, EN 60825-1, FCC Part 15, Class A |
