Sold out
JL310A
Model: Aruba JL310A – Aruba Switches Transceivers
Details: Aruba 100G QSFP28 LC LR4 SMF XCVR
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
JL310A Overview
Quick Specs Figure 1 shows the appearance of JL310A.
Table 1 shows the Quick Specs.
| Specification | Description |
| Product Model | JL310A |
| Brand | Aruba |
| Connectivity | 100G QSFP28 |
| Connector Type | LC |
| Transmission | LR4 |
| Fiber Type | Single Mode Fiber (SMF) |
| Wavelength | 4 Lambda (1271 nm, 1291 nm, 1311 nm, 1331 nm) |
| Data Rate | 100 Gbps |
| Transmission Distance | Up to 10 kilometers |
| Operating Temperature | -5°C to 70°C |
| Domestic/Import | Import |
| Form Factor | Hot-Pluggable |
| Power Supply Voltage | 3.3V |
| Power Consumption | 5W |
| Max Reach Supported | Up to 10 kilometers |
| Compatibility | Aruba switches and network devices |
| Supported Protocols | 100 Gigabit Ethernet, 4x 25 Gigabit Ethernet |
| Optical Components | DFB Laser |
| Dimensions | 70 mm x 13.5 mm x 18 mm |
