Sold out
Juniper ACX5096-AC-L2-L3
Model: Juniper ACX5096-AC-L2-L3 Routers
Details: ACX5096, 96 SFP+/SFP ports, 8 QSFP ports, redundant fans and AC power supplies; No right to use IP-VPN
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
Juniper ACX5096-AC-L2-L3 Overview
Quick Specs Figure 1 shows the appearance of Juniper ACX5096-AC-L2-L3.
Table 1 shows the Quick Specs.
| Brand | Juniper |
| Model | ACX5096-AC-L2-L3 |
| Port Configuration | 96 SFP+/SFP ports |
| Additional Ports | 8 QSFP ports |
| Redundant Fans | Yes |
| Power Supply | Redundant AC power supplies |
| IP-VPN | No right to use IP-VPN |
| Physical Dimension | 1U |
| Operating Temperature Range | 0??C to 40??C (32??F to 104??F) |
| Storage Temperature Range | -40??C to 70??C (-40??F to 158??F) |
| Humidity | 5% to 90% non-condensing |
| Power Consumption | 550W |
| Forwarding Capacity | 1.2 Tbps |
| Packet Forwarding Rate | 960 Mpps |
| Junos OS | Supported |
| Layer 2 Features | Supported |
| Layer 3 Features | Supported |
| Management Ports | 1 console port, 1 management port |
| LED Indicators | Port status, System status |
| Noise Level | 62 dB(A) (max) |
| Mounting | Rack-mountable |
