Juniper JNP-QSFP-100G-LR4
Model: Juniper JNP-QSFP-100G-LR4 Switches
Details: QSFP28 100GBase-L4 Optics for up to 10km transmission over serial SMF
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
Juniper JNP-QSFP-100G-LR4 Overview
Quick Specs Figure 1 shows the appearance of Juniper JNP-QSFP-100G-LR4.
Table 1 shows the Quick Specs.
| Product Name | Juniper JNP-QSFP-100G-LR4 |
| Form Factor | QSFP28 |
| Data Rate | 100 Gbps |
| Wavelength | LAN WDM (1295.56, 1300.05, 1304.58, 1309.14 nm) |
| Interface | LC duplex |
| Cable Type | Single-mode Fiber (SMF) |
| Transmission Distance | Up to 10 km |
| Protocols Supported | 100 Gigabit Ethernet, MSA Compliant |
| Operating Temperature | 0��C to 70��C |
| Max Power Consumption | 3.5W |
| Diagnostics Support | Digital Optical Monitoring (DOM) |
| Hot Swappable | Yes |
| MTBF | High reliability with an MTBF (mean time between failures) of over 300,000 hours |
| Compatibility | Compatible with Juniper Networks devices and intended for use in Juniper platforms |
| Applications | Designed for use in 100G Ethernet links, data center, and high-performance computing networks |
| Certifications | Compliant with QSFP28 MSA, IEEE 802.3ba 100GBASE-LR4 standards |
| Modulation Format | 4-lane LAN-WDM |
| Receiver Sensitivity | -10.6 dBm (maximum) |
| Transmitter Power | -4.3 to 4.5 dBm (per lane) |
| Connector Type | LC |
| Electrical Interface | CAUI-4 (100G Ethernet) |
