Juniper QFX5110-48S-AFI2
Model: Juniper QFX5110-48S-AFI2 Switches
Details: 48 SFP+ and 4 QSFP28, back to front air flow, AC
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
Juniper QFX5110-48S-AFI2 Overview
Quick Specs Figure 1 shows the appearance of Juniper QFX5110-48S-AFI2.
Table 1 shows the Quick Specs.
| Dimensions(W x H x D) | 1.72 x17.36 x 20.48 in (4.37 x 44.09 x 52.02 cm) |
| Rack units | 1 U |
| Weight | 23 lb (10.43 kg) |
| Operating system | Junos OS |
| CPU | 1.8 GHz quad-core Intel CPU |
| Power | *AFO/AFI: Max load: 300 W, Typical load: 195 W, Idle load: 150 W*Dual redundant (1+1) and hot-pluggable power supplies*110-240 V single phase AC power*-36 to -72 V DC power |
| Cooling | *Redundant (N+1) and hot-pluggable fan modules for front-to- back and back-to-front airflow*Redundant variable-speed fans to reduce power draw |
| Total packet buffer | 16 MB |
| Warranty | Juniper standard one-year warranty |
| System Throughput | Up to 1.76 Tbps (bidirectional) |
| Forwarding Capacity | 1.32 Bpps |
| Interface Options | *1GbE SFP: 48 (24 copper 1GbE)*10GbE SFP+: 48/64 (with breakout cable)*40GbE QSFP+: 4*100GbE QSFP28: 4 |
| Other Interface Notes | *Each QSFP+ port can be configured as a 4 x 10GbE interface or as a 40 Gbps port*Each QSFP28 port can be configured as a 4 x 10GbE interface a 40 Gbps port or as a 100 Gbps port*1 USB 2.0 port*1 RS-232 console port*2 management ports: 2x SFP fiber ports or 1x RJ-45 and 1x copper SFP ports*Supported transceiver and direct attach cable*SFP+ 10GbE optical modules*SFP+ DAC cables: 1/3/5 m twinax copper and 1/3/5/7/10 m active twinax copper*SFP GbE optical and copper module*QSFP+ DAC cables: 1/3/5 m twinax copper and 7/10 m active twinax copper*QSFP+ AOC cables: 1/3/5/7/10/15/20/30 m cable*QSFP+ Optics: SR4, LX4, ESR4, IR, LR4*QSFP+ to SFP+ 10GbE direct attach breakout copper (1/3/10 m twinax copper and 5/7 m active twinax copper cable)*QSFP28 Optics: SR4, CWDM4, LR4*QSFP28 AOC: 10 m cable |
| MAC addresses per system | 288,000 |
| VLAN IDs | 4,093 |
| Number of link aggregation groups (LAGs) | 104 |
| Number of ports per LAG | 32 |
| Firewall filters (ingress / egress) | 6,142 / 1,022 |
| IPv4 unicast routes | 128,000 prefixes; 208,000 host routes; 64 ECMP paths |
| IPv4 multicast routes | 104,000 |
| IPv6 unicast routes | 84,000 |
| IPv6 multicast routes | 52,000 |
| ARP entries | 48,000 |
| Jumbo frame | 9,216 bytes |
| Spanning Tree Protocol (STP) | *Multiple Spanning Tree Protocol (MSTP) Instances: 64*VLAN Spanning Tree Protocol (VSTP) Instances: 253 |
| Traffic mirroring | *Mirroring destination ports per switch: 4*Maximum number of mirroring sessions: 4*Mirroring destination VLANs per switch: 4 |
| Operating temperature | 32° to 104° F (0° to 40° C) |
| Storage temperature | -40° to 158° F (-40° to 70° C) |
| Operating altitude | Up to 2,000 ft (610 m) |
| Relative humidity operating | Operating: 5% to 90% (noncondensing) |
| Relative humidity non-operating | Non-operating: 0% to 95% (noncondensing) |
