Lenovo ST558 Intel 3204/16GB DDR4/4×3.5 Hot plug bay/No disk/R530-8i/550W

Original price was: $1,813.90.Current price is: $1,723.21.

Model: Lenovo ThinkSystem ST558 Tower Servers
Details: Lenovo Server ST558 1×3204 6C 1.9GHz, 1x16GB DDR4, 4×3.5 Hot plug bay, No disk, R530-8i, 550W Platinum Redundant Single PS, DVDRW, 3-year limited warranty and door-to-door S-ERVER
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

Add to quote
Add to compare
Add to wishlist
SKU: Lenovo ST558 Intel 3204/16GB DDR4/4x3.5 Hot plug bay/No disk/R530-8i/550W Categories: , ,
Description

Lenovo ST558 Intel 3204/16GB DDR4/4×3.5 Hot plug bay/No disk/R530-8i/550W Overview

Quick Specs Figure 1 shows the appearance of Lenovo ST558 Intel 3204/16GB DDR4/4×3.5 Hot plug bay/No disk/R530-8i/550W.

Table 1 shows the Quick Specs.

Machine type 7X09 – 1 year warranty7X10 – 3 year warranty
Form factor Tower or 4U Rack.
Processor One or two Intel Xeon Processor Scalable Family of processors, either Bronze, Silver, Gold or Platinum-level processors (formerly codename “Skylake”). Supports processors up to 20 cores, core speeds up to 3.6 GHz, and TDP ratings up to 125W. Two Intel Ultra Path Interconnect (UPI) links at 10.4 GT/s each.
Chipset Intel C624 “Lewisburg” chipset
Memory Up to 12 DIMM sockets (6 DIMMs per processor) supporting Lenovo TruDDR4 DIMMs at up to 2666 MHz. RDIMMs and LRDIMMs (Load Reduced DIMMs) are supported, but memory types cannot be intermixed.
Memory maximums With RDIMMs: Up to 384 GB with 12x 32 GB RDIMMs and two processorsWith LRDIMMs: Up to 768 GB with 12x 64 GB LRDIMMs and two processors
Memory protection ECC, SDDC (for x4-based memory DIMMs), ADDDC (for x4-based memory DIMMs, requires Intel Xeon Gold or Platinum processors), memory mirroring, and memory sparing.
Disk drive bays Available configurations:8, 16, or 20x 2.5-inch SAS/SATA hot-swap (optional support for NVMe drives)4 or 8x 3.5-inch SAS/SATA hot-swapBoth 8x 3.5-inch + 4x 2.5-inch SAS/SATA hot-swap4 or 8x 3.5-inch SATA simple-swapAdditional drive bays (except for 20-bay and hybrid configurations):Two 5.25-inch drive bays for optical drives
Maximum internal storage 2.5-inch drives:153.6TB using 20x 7.68TB 2.5-inch SAS/SATA SSDs30.72TB using 4x 7.68TB 2.5-inch NVMe SSDs48TB using 20x 2.4TB 2.5-inch HDDs3.5-inch drives:144TB using 8x 18TB 3.5-inch HDDs61.44TB using 8x 7.68TB 3.5-inch SAS/SATA SSDs
Storage controller Onboard 6 Gb SATA for simple-swap drive configurations, using embedded Intel RSTe software RAID, supporting RAID 0, 1, 10, 5, 5012 Gb SAS/SATA RAID for hot-swap drive configurations:RAID 530i (cacheless) supports RAID 0, 1, 10, 5, 50RAID 730-8i with 1GB cache supports RAID 0, 1, 10, 5, 50RAID 730-8i with 2GB flash-backed cache supports RAID 0, 1, 10, 5, 50, 6, 60RAID 930-8i with 2GB flash-backed cache supports RAID 0, 1, 10, 5, 50, 6, 60RAID 930-16i and 24i with 4GB flash-backed cache supports RAID 0, 1, 10, 5, 50, 6, 6012 Gb SAS/SATA non-RAID: 430-8i and 430-16i HBAs
Optical drive bays Two half-height 5.25-inch bays for optical or tape drives. Supports DVD-ROM or Multiburner. Hot-swap bays can be converted to 4x 2.5-inch hot-swap drive bays. (Not available with simple-swap drive configurations.)
Tape drive bays Two half-height 5.25-inch bays for optical or tape drives. Support for one RDX drive or LTO tape drive.
Network interfaces Two integrated Gigabit Ethernet 1000BASE-T ports (RJ-45) based on Intel X722 embedded controller (No 10/100 Mbps support)
PCI Expansion slots Up to 7 PCIe slots: 6 general purpose PCIe 3.0 slots plus one slot reserved for the M.2 adapter. General purpose slots are as follows:Slot 1: PCIe 3.0 x8 (25W) FHHLSlot 2: PCIe 3.0 x16 (75W); FHHLSlot 3: PCIe 3.0 x16 (75W); FHFLSlot 4: PCIe 3.0 x16 (x8 wired) (25W); FHFL (requires second processor)Slot 5: PCIe 3.0 x16 (75W); FHFL (requires second processor)Slot 6: PCIe 3.0 x8 (x4 wired) (25W); FHFLSlots 3 and 5 support double-wide GPUs
Ports Front: Two USB ports (one USB 3.0, one USB 2.0 portRear: Six USB ports (four USB 2.0, two USB 3.0), one VGA video, one RJ-45 systems management, two RJ-45 GbE network ports, optional serial port.Internal: One internal USB 3.0 port for RDX drive
Cooling Supports ASHRAE A2 environments as well as A3/A4 with some limitations. Up to four simple-swap fans: two fans shipped standard on single processor models and three fans shipped on dual processor models or models where there are drive bays in lieu of the optical drive bays. The fourth rear-mounted fan is N+1 redundant, except for certain configurations.
Power supply Up to two redundant hot-swap 550 W, 750 W or 1100 W High Efficiency Platinum AC power supplies, or 750 W High Efficiency Titanium AC power supplies. Also available is a 450 W fixed (non-hot-swap) power supply. In China only, all hot-swap power supplies also support 240V DC.
Hot-swap parts Hard drives, power supplies, and fans
Systems management Operator panel with status LEDs. XClarity Controller embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management. Optional XClarity Controller Advanced to enable remote control functions.
Security features Power-on password, administrator’s password, Trusted Platform Module (TPM), supporting TPM 1.2 or TPM 2.0. In China only, optional Trusted Cryptographic Module (TCM). Kensington cable slot. Lockable side cover. Optional lockable front security door and chassis intrusion switch (included with some models).
Video G200 graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity Controller. Maximum resolution is 1920×1200 32bpp at 60Hz.
Operating systems supported Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi.
Limited warranty Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9×5 next business day (NBD).
Service and support Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications.
Dimensions Width: 176 mm (6.9 in.), height: 438 mm (17.2 in.), depth: 660 mm (26 in.)
