Sold out
MX-MPC1-3D-Q-R-B
Model: Juniper MX-MPC1-3D-Q-R-B
Details: MX240/480/960
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
MX-MPC1-3D-Q-R-B Overview
Quick Specs Figure 1 shows the appearance of MX-MPC1-3D-Q-R-B.
Table 1 shows the Quick Specs.
| Brand | Juniper |
| Model | MX-MPC1-3D-Q-R-B |
| Product Level | High-Performance |
| Router Platform Compatibility | MX240, MX480, MX960 |
| Port Density | Up to 32 ports per slot |
| Forwarding Capacity Per Slot | 120 Gbps |
| Forwarding Technology | 3D Forwarding |
| Packet Forwarding Rate | 180 Mpps |
| Control Plane Memory | Up to 4 GB |
| MAC Entries | 512,000 |
| IPv4 Routes | 1,000,000 |
| IPv6 Routes | 512,000 |
| ACL Entries | 128,000 |
| J-Flow Entries | 2,000,000 |
| Label Switched Paths | 256,000 |
| Management Interfaces | 10/100/1000 Base-T Ethernet |
| Supported Protocols | OSPF, IS-IS, BGP, MPLS, LDP, RSVP-TE |
| QoS Features | Hierarchical Quality of Service |
| Operating Temperature | 0??C to 40??C |
| Power Consumption | 420 W |
