N3248X-ON
Model: N3248X-ON – Dell EMC Networking PowerSwitch N3200 Series Series
Details: Dell N3248X-ON, 48×1/2.5/5/10G RJ-45, 4x25G SFP28, 2x100G QSFP28, 1xAC PSU, IO/PS, OS6
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
N3248X-ON Overview
Quick Specs Figure 1 shows the appearance of N3248X-ON.
Table 1 shows the Quick Specs.
| Model | N3248X-ON |
| Ports | 48x 1/2.5/5/10G RJ-45 |
| Uplink Ports | 4x 25G SFP28 |
| High-Speed Ports | 2x 100G QSFP28 |
| Power Supply Unit | 1x AC PSU |
| Direction | IO/PS |
| Operating System | OS6 |
| Switching Capacity | 2.4 Tbps |
| Forwarding Rate | 1.8 Bpps |
| Latency | <2.5 ��s |
| Jumbo Frames | Up to 9216 bytes |
| MAC Address Table | 128K entries |
| VLAN IDs | 4096 |
| Multicast Groups | 4K |
| Queue | 8 queues per port |
| Energy Efficient Ethernet (EEE) | Supported |
| Power Consumption | Up to 300 W |
| Environmental Compliance | EPA Energy Efficient, RoHS |
| Dimension (W x D x H) | 44.3 cm x 50.8 cm x 4.32 cm |
| Rack Units | 1 RU |
| Operating Temperature | 0��C to 45��C (32��F to 113��F) |
| Storage Temperature | -40��C to 70��C (-40��F to 158��F) |
